Description

– Comes with 300W Micro ATX PSU
– Comes with 1 x 8cm Top Cooling Fan
– Built-in Card Reader – Supports SD/MMC, CF/MD, XD, TF, MS/M2
– Supports Micro ATX Power Supplies

PSU Included
Yes
300W

PSU Specification
Rail: Max. DC Output
+3.3V: 16A
+5V: 16A
+12V: 14A
-12V: 0.3A
+5VSB: 2A

PSU Connectors
20 + 4 Pin ATX: 1
+12V 4Pin CPU: 1
4 Pin Molex: 2
SATA: 3
FDD: 1

Form Factor
Thin Client Micro ATX

Motherboard Support
Micro ATX
Mini-ITX

PSU Support
Micro ATX

PSU Location
Front

Water Cooling Ready
No

Body Material
0.5mm SECC Metal

Front Bezel Material
Plastic

Side Panel
Vented

Drive Bays
1 x 5.25″ External
2 x 3.5″ Internal / 2 x 2.5″ Internal
(1 x 2.5″ uses a 3.5″ bay)

Expansion
Slots: 4 x Half-Height

Cooling
Cooling Front:None
Cooling Top:1 x 8cm
Cooling Rear:None
Cooling Side:Vent
Cooling Bottom:Vent and Space for 1 x 50mm fan (Not Included)

IO Ports
2 x USB 2.0
1 x HD Audio
1 x Microphone
SD/TF Card Reader Included (Built-in)

Clearence
GPU Max Length:225mm
CPU Cooler Maximum Height:82mm

Front Bezel Colour
Gloss Black

Body Colour
Gloss Black

Dimensions ( W x H x D )
100 x 306 x 399 mm

Weight
3.2 kg
