Description

ECLIPSE P400S TEMPERED GLASS
Phanteks continues its user friendly design chassis with the new Eclipse Series P400S.

Without much effort, the P400S allows users to create a clean and beautiful system. Ambient RGB illumination adds character while the solid metal exterior gives the case a simple elegant design. The P400S is suitable for beginners and experienced system builders with all the extra features. The P400S comes with sound damping panels and a 3-speed fan controller to enhance acoustical performance.

Phanteks’ budget-friendly Exlipse P400S now sports an all new tempered glass side panel. The new variant of the Eclipse Series still featurs the solid build quality, built-in RGB lighting controller, open interior design, compatibility with all-in-one liquid cooling. The P400S retains the 3 speed fan controller and noise deadening material for a more silent build. The tempered glass side panel of the Eclipse P400S offers elegance and style to your system build.

Features:
– Full Metal Body
– Clean interior – Featuring a PSU cover
– Fully Equipped with Dust Filters
– Ready for AIO Watercooling: Supports up to 360 Radiators
– Upgrade Options: Up to 4 x Extra HDD’s
– Equipped with 2 x 120mm fan
– Equipped with Phanteks’ velcro cable ties
– 25mm cable management space + additional cable compartment in bottom
– Front I/O (Hidden): 2 x USB 3.0 / Headphone / Mic / LED Control / Reset / 3-Speed Fan Controller
– RGB Power Light + Ambient Down Lights: Choose from 10 Differend Colours
– Internal RGB Lighting: Phanteks RGB LED Strip Included

Model Number
PH-EC416PSTG_BK
Phanteks Eclipse P400S Tempered Glass Edition Side Window Panel Satin Black

Dimensions ( W x H x D )
210 x 465 x 470 mm

Form Factor
Full Tower

Materials
Steel chassic
Steel exterior
ABS
Glass

Motherboard Support
E-ATX (up to 272 mm wide, cannot use rubber grommets)
ATX
Micro ATX
Mini-ITX

Front I/O
2 x USB 3.0.
Mic
Headphone
Reset
LED control
3-speed Fan controller (only available for P400S)

Side Window
Yes
Tempered Glass

Expansion & Drive Bays
Expansion Slots: 7
Internal 3.5″: 6 (2 x included)
Internal (dedicated) 2.5″: 2 (2 x included)

Cooling
Front: 3 x 120mm Fan (1 x included) / 2 x 140mm Fan
Top: 2 x 120mm Fan / 2 x 140mm Fan
Rear: 1 x 120mm Fan (1 x included)

Liquid Cooling
Front: 120mm Radiator (Up to 360*) / 140mm Radiator (up to 280)
Rear: 120
*360 radiator requires the removal of the midplate cover

Clearence
Graphic Card: 395mm (15.2 in)
CPU Cooler: 160mm (6.3 in)
Cable Management: 25mm (1.0 in)
PSU (including cable): 270mm (10.6 in)

Weight
Net Weight: 7 kg
Gross Weight: 8 kg

Colour
Satin Black

Accessories
N/A
